Main Power:55 KW three phases
final pellet size:1.5-12 mm
used for: making fish feed,chicken feed,cattle feed,poultry feed
raw materials:grains,manure,straw meal,alfalfa,bone meal etc
Ring die pellet mill machine is another popular type. they have higher quality than flat die pellet machine,In contrast to flat die pellet press machines, ring die pellet mill are more often used for commecial and big capacity plant like chicken feed,pig feed,duck feed,fish feed,cattle feed,also for manufacturing wood pellets and biomass pellets. The finished feed pellets have a smooth surface and easy to digest for animals. As the die’s name suggests, the ring die has a wide cylindrical shape and is mounted vertically, rather than flat,Ring Die pellet macine adopts mature technology to make high quality animal feed pellet with large-scale production. Based on the outstanding features of its high throughput, low consumption.if you would like a small production capacity,we advise to use flat die pellet mill.this ring die pellet mill can produce poultry feed pellets and sinking fish feed pellets,
* ring die pellet mill adopt three layer jacket conditioner, the material can be fully cooked, meet special needs and ensure quality of final aquatic feed.
* Main driving adopts high precision gear transmission , the capacity can be improved about 20% compared to the belt transmission, and with low energy-consumption.
* Multiple aperture ring die for choice, excellent craft of ring die with long service life to make smooth and high quality aquatic feed pellets.
* The international advanced spring coupling device is of novel and compact structure, safety, reliable, low noise and low failure rate.
* Applicable for large-scale production of high quality aquatic feed pellets,wood pellets and biomass pellets
There are two main advantages in using ring die pellet mill. First, generate less wear and tear since both the inner and outer edges of the roller traverse the same distance. Second, more energy efficient the flat die pellet mill design. Roller slip during the pelleting process brings extra friction, but this extra friction is a good element in the production of quality wood pellets due to the additional heat.
die inner diameter
|HMK-320||2–3 t/h||37 kw||0.75 kw||2.2 kw||320 mm||1.5–8mm|
|HMK-350||3–4 t/h||55 kw||0.75 kw||2.2 kw||350 mm||1.5–8mm|
|HMK-400||4–5 t/h||75 kw||1.5 kw||2.2 kw||400 mm||1.5–8mm|
|HMK-420||5–7 t/h||90 kw||1.5 kw||5.5 kw||420 mm||1.5–8mm|
